In 1945, an Enigma machine sank to the floor of the Baltic Sea. For decades it sat there, its rotors locked, its wiring intact, waiting. When divers finally pulled it from the silt, the mechanism still worked. The genius was never in the shell. It was in the rotors, the wiring, the algebra of permutations hidden inside.

Enigma DSL is built on the same principle. Inspired by NVIDIA's CuTe DSL, which brought layout algebra and tiling calculus to CUDA, Enigma brings the same mathematical framework to Apple Metal. Where CuTe targets tensor cores and warps on NVIDIA GPUs, Enigma targets simdgroups and threadgroups on Apple Silicon. The layout algebra is the same. The target is different. You write a Python function. Underneath, the algebra computes how threads map to memory, how tiles partition a tensor, how values flow through a simdgroup. The Python traces into an IR. The IR emits Metal C++. The Metal compiles to GPU machine code. Your function runs on Apple Silicon at hardware bandwidth limits. The surface is clean. The machinery is exact.

---

Enigma is a Python DSL for writing Apple Metal GPU compute kernels. You write a Python function decorated with @enigma.kernel; Enigma traces it into MLIR, emits Metal Shading Language, compiles through xcrun metal, and dispatches on the GPU through a Swift runtime. The DSL surface is small. The generated kernels run at hand-written-Metal bandwidth.

Inspired by NVIDIA's CuTe DSL — Enigma brings the same layout-algebra and tiling calculus to Apple Silicon. CuTe targets warps and tensor cores; Enigma targets simdgroups and threadgroups.

Pipeline

Python @enigma.kernel  →  traced IR  →  MLIR (enigma dialect)  →  MSL
                                                                    ↓
                                                   xcrun metal → AIR
                                                                    ↓
                                              xcrun metallib → .metallib
                                                                    ↓
                                              Swift runtime (ctypes) → GPU

For tiled kernels, @enigma.jit runs CuTe-style layout algebra host-side before launching: composition, complement, coalesce, zipped divide, and the make_layout_tv constructor that maps thread × value indices to tile coordinates with correct coalescing order. The entire vectorisation strategy is decided at trace time; only the resulting offsets and memory transactions reach the GPU.

Install

Requirements: Apple Silicon Mac (M1 through M5), macOS 14 / 15 (or any newer release), Python 3.11 / 3.12 / 3.13.

pip install enigma-dsl

That single command pulls a self-contained wheel that bundles the Python DSL and the native MLIR dialect (libLLVM, libMLIRPythonCAPI, the Enigma dialect .so) — no separate steps, no LLVM toolchain on your machine. pip picks the right wheel for your Python version and macOS version automatically.

The release ships six wheels: 3 Python versions × 2 macOS deployment targets (14.0 and 15.0). macOS 14-tagged wheels run on macOS 14, 15, 26 and every future version; macOS 15-tagged wheels are picked first on macOS 15+ hosts because pip prefers the most specific match.

Quick verification:

python -c "import enigma; print(enigma.__version__)"
# 0.1.1

30-second example

Save as add.py and run with python add.py — no setup beyond pip install enigma-dsl numpy. This is the shortest end-to-end trace → MSL codegen → GPU dispatch you can write.

import numpy as np
import enigma

@enigma.kernel
def add(A: enigma.f32, B: enigma.f32, C: enigma.f32):
    i = enigma.thread_position_in_grid
    C[i] = A[i] + B[i]

compiled = enigma.compile(add)

N = 1024
a = np.random.randn(N).astype(np.float32)
b = np.random.randn(N).astype(np.float32)

raw = enigma.MetalRuntime().execute(
    compiled, inputs=[a, b], output_size=N * 4,
    grid=(N, 1, 1), threads=(256, 1, 1),
)
c = np.frombuffer(raw, dtype=np.float32)
print("max |error| =", float(np.max(np.abs(c - (a + b)))))   # 0.0

What ran:

1. @enigma.kernel traced the Python function into MLIR (the enigma dialect).
2. enigma.compile lowered it to Metal Shading Language, then ran it through xcrun metal → AIR → xcrun metallib → .metallib.
3. MetalRuntime().execute(...) mmap'd the .metallib, allocated GPU buffers, dispatched the compute pass, and returned the result bytes.

For richer examples — RMSNorm, FlashAttention, 1D Laplacian — see the Showcase kernels section below.

Building from source

You only need this path if you are hacking on the dialect itself, or porting to a future LLVM. The pipeline is two stages — dialect (native, C++/MLIR) first, then the Python DSL on top of it.

git clone https://github.com/Klyne-org/Enigma-DSL.git
cd Enigma-DSL
git submodule update --init --recursive   # pulls Enigma-Dialect

# Stage 1: build LLVM 22.x + MLIR (one-time, ~30-90 min).
# Produces ~/.local/enigma-llvm/ — isolated from any Homebrew LLVM.
bash scripts/build_llvm.sh

# Stage 2: build the merged wheel (DSL + dialect) for the Python
# version of your choice. Repeat the --python flag for each version.
bash scripts/build_all.sh --python 3.12

# The wheel lands in wheelhouse/. The script also creates a venv
# (.venv for 3.12, .venv-py<X.Y> otherwise), installs into it, and
# runs pytest by default.

What scripts/build_all.sh actually does, in order:

1. Sources ~/.local/enigma-llvm/activate.sh to put the local MLIR on MLIR_DIR / LLVM_DIR (skipped if MLIR_DIR is already set, or if --skip-dialect is passed).
2. Builds enigma-dsl as a pure-Python wheel (py3-none-any).
3. Builds enigma-dialect as a native wheel (cpXY-cpXY-macosx_*_arm64) — one per Python version. This invokes scikit-build-core which in turn drives CMake against the local LLVM build.
4. Fixes Mach-O rpaths and re-codesigns the bundled dylibs so they load from @loader_path.
5. Merges the two wheels into a single enigma_dsl-*-cpXY-cpXY-*.whl containing both enigma/ and mlir/ packages — what users eventually pip install from PyPI.
6. Creates a per-Python venv, installs the merged wheel into it, and runs pytest tests/ (steps 5–6 are skipped by the corresponding --no-merge / --no-install / --no-test flags).

The macOS deployment target defaults to the host's OS major (Darwin 24 → macOS 15.0, Darwin 23 → macOS 14.0); override it with --macos.

Common variations:

# Multi-version build (publish-ready):
bash scripts/build_all.sh --python 3.11 --python 3.12 --python 3.13 \
                          --macos 14.0 --no-test --no-install --clean

# Build the dialect against an existing LLVM in a non-default location:
MLIR_DIR=/path/to/lib/cmake/mlir \
  bash scripts/build_all.sh --python 3.12

# Build only the dialect (skip Python DSL):
bash scripts/build_all.sh --python 3.12 --skip-dsl

# Build only the DSL (reuse a previously built dialect wheel):
bash scripts/build_all.sh --python 3.12 --skip-dialect

# Keep the two wheels separate instead of merging them:
bash scripts/build_all.sh --python 3.12 --no-merge

# Write wheels to a custom directory instead of ./wheelhouse:
bash scripts/build_all.sh --python 3.12 --out /tmp/wheels

The LLVM step is the expensive one. After the first build_llvm.sh finishes, every subsequent build_all.sh reuses it — incremental dialect builds are ~3-5 min per Python. Pass --clean to wipe the build caches and rebuild from scratch.

Hello, Metal

import numpy as np
import enigma

@enigma.kernel
def vector_add(A: enigma.f32, B: enigma.f32, C: enigma.f32):
    tid = enigma.thread_position_in_grid
    C[tid] = A[tid] + B[tid]

compiled = enigma.compile(vector_add)
print(compiled.metal_source)   # generated MSL — readable, debuggable

N = 1024
a, b = np.random.randn(N).astype(np.float32), np.random.randn(N).astype(np.float32)

runtime = enigma.MetalRuntime()
raw = runtime.execute(compiled, inputs=[a, b], output_size=N * 4,
                      grid=(N, 1, 1), threads=(256, 1, 1))
c = np.frombuffer(raw, dtype=np.float32)
assert np.allclose(c, a + b)

Showcase kernels

The examples/ directory has four end-to-end showcase kernels. Each ships in three forms: the Enigma DSL version, the equivalent handwritten Metal shader for comparison, and (where applicable) a benchmark harness that times both.

Kernel	DSL	Handwritten	What it shows
Vector add	vector_add.py, vector_add_tv.py	vector_add_naive.metal, vector_add_float4.metal, add_kernel_tv.metal	The hello-world. The TV variant uses @enigma.jit + layout algebra to choose vectorisation.
RMSNorm	benchmark_rmsnorm.py	rmsnorm_handwritten.metal	Reduction across a row, threadgroup shared memory, simd_sum. The benchmark times Enigma vs handwritten side-by-side.
SDPA / FlashAttention	benchmark_sdpa.py, showcase_attention.py	sdpa_handwritten.metal	Fused attention forward — online softmax, multi-simdgroup tiling, threadgroup reductions.
1D Laplacian	conv1d_laplacian.py	conv1d_laplacian_handwritten.metal	Finite-difference stencil for PDE solvers (heat eq., diffusion). Boundary handling via enigma.if_.

Run any of them directly:

python examples/conv1d_laplacian.py     # prints generated MSL + numpy diff
python examples/benchmark_rmsnorm.py    # benchmarks Enigma vs handwritten
python examples/showcase_attention.py   # FlashAttention forward

Benchmarks

Measured on a MacBook Air M4 (8-core GPU, 16 GB unified memory, 120 GB/s memory bandwidth, ~3.6 TFLOPS FP32 theoretical peak). All kernels pass correctness against a NumPy reference.

Qwen3-0.6B fused decode — examples/qwen_megakernel.py

Single-dispatch megakernel: RMSNorm → QKV proj → head-norm + RoPE → SDPA → O-proj → SwiGLU → down-proj, all in one threadgroup.

Metric	Value
Throughput	92.6 tok/s
Latency	10.79 ms/tok
Compile time	0.08 s (14 KB of generated MSL)
Correctness	`max

Reproduce:

python examples/benchmark_sdpa.py
python examples/qwen_megakernel.py

What's in the box

• Kernel surface: arithmetic, unary/binary/ternary float math, integer intrinsics (popcount, clz, mulhi, …), vector ops (make_float4, dot, cross, length, …), pack/unpack ops, comparisons, select/where, if_, for_range, casts, atomics with explicit memory order.
• GPU-specific: thread/threadgroup/grid queries, simdgroup reductions and shuffles, quad-group ops, threadgroup shared memory and barriers, simdgroup matrix ops on Apple's hardware matrix units.
• Layout algebra (CuTe-style): Layout, Shape, Stride with composition, complement, coalesce, recast, zipped divide. The make_layout_tv constructor builds Thread × Value layouts.
• Two compilation paths: @enigma.kernel (raw, you set the grid) and @enigma.jit (layout-driven, the engine sets the grid).
• Compatibility: tested on Apple M-series GPUs through xcrun metal / xcrun metallib. Float32, float16, bfloat16, integer widths 8–64.

Documentation

• docs/api-reference.md — exhaustive op-by-op reference (30 sections, every primitive).
• Enigma-Dialect/ — submodule with the C++/MLIR dialect definition, MSL emitter, and dialect-level lit tests.

Testing

python -m pytest tests/                              # full Python suite
bash Enigma-Dialect/test/run_tests.sh                # MLIR/lit suite
bash Enigma-Dialect/test/run_tests.sh --gpu          # plus GPU dispatch

License

MIT. See LICENSE.

Versions

v0.1.1 — first PyPI release. Six merged wheels published (enigma_dsl-0.1.1-cp{311,312,313}-cp{311,312,313}-macosx_{14_0,15_0}_arm64). Installable via pip install enigma-dsl on any Apple Silicon Mac running macOS 14+. Project page: https://pypi.org/project/enigma-dsl/.

v0.1.0 — initial release. Layout algebra engine (composition, complement, coalesce, zipped divide, recast, TV layout construction). Tracing IR with SSA values, constant folding, thread index decomposition. Metal emitter supporting scalar, float4 vector pointer, and TV-layout vectorised codegen. Swift runtime with device management, buffer allocation, synchronous dispatch, GPU timestamp measurement. Dialect TableGen definitions covering thread indexing, synchronisation, math, atomics, simdgroup, quad, geometry, pack/unpack, and matrix ops.
