CALMGuard

From Architecture-as-Code to Continuous Compliance — Automatically.

CALMGuard is a CALM-native continuous compliance DevSecOps platform. Describe your architecture using the FINOS CALM standard, and CALMGuard deploys a squad of AI agents to analyze compliance gaps, score risk, and generate production-ready CI/CD pipelines — all streamed in real-time to an interactive dashboard.

Built for the DTCC/FINOS Innovate.DTCC AI Hackathon (Feb 23–27, 2026).

Key Features

AI Agent Squad	Compliance Skills	Learning Intelligence	GitOps Integration
6 agents: Scout, Ranger, Arsenal, Sniper, Oracle, HQ	7 skill files with 100+ KB of regulatory knowledge	Self-learning engine with pattern fingerprinting	Fetch CALM from GitHub, generate PRs
Multi-provider LLM: Gemini, Claude, GPT, Grok	SOX, PCI-DSS, NIST-CSF, FINOS-CCC, SOC2, Protocol Security	Auto-promotes patterns to deterministic rules after 3 observations	DevSecOps CI pipeline and compliance remediation PRs
Parallel Phase 1 + sequential Phase 2 orchestration	Closed Control ID Reference tables prevent LLM hallucination	Phase 0 Oracle fires instant findings before LLM agents start	Full repo-connected workflow with SHA tracking

CALM Parser	Real-Time Dashboard	DevSecOps Pipeline Generator
Multi-version CALM support (v1.0, v1.1, v1.2) with Zod validation	React Flow architecture graphs with touring camera animation	GitHub Actions CI with 6 DevSecOps stages
Auto-detects version, normalizes legacy types, lenient parsing	Live SSE streaming with agent status indicators	SAST (Semgrep), SCA (Trivy), Secrets (Gitleaks), SBOM (Syft)
Demo architectures included	Compliance gauges, risk heat maps, exportable reports	Security-focused Terraform IaC from CALM signals

How It Works

┌─────────────┐     ┌──────────────────┐     ┌──────────────────┐     ┌─────────────────┐
│  1. Connect  │────▶│  2. Pre-Check     │────▶│  3. Analyze       │────▶│  4. Act          │
│  CALM JSON / │     │  Oracle fires     │     │  AI Agent Squad   │     │  PRs, Pipelines, │
│  GitHub Repo │     │  learned rules    │     │  scores & maps    │     │  Reports, Learn  │
└─────────────┘     └──────────────────┘     └──────────────────┘     └─────────────────┘

Connect — Upload a CALM architecture JSON, fetch from GitHub, or use built-in demos
Pre-Check — Oracle fires deterministic rules from previously learned patterns (zero-latency, no LLM)
Analyze — Squad of LLM agents assesses compliance across 5 frameworks, scores risks, generates CI pipelines and cloud infrastructure
Act — Generate CI/CD pipelines, remediation PRs, compliance reports — and learn patterns for next time

Demo and Presentation

You could Access the Presentation -> usin this link. Following that watch the demo video by clicking the image below.

Watch the demo on YouTube

Quick Start

Prerequisites

Node.js 22+ and pnpm 9+
At least one LLM provider API key (Gemini is the default)

Setup

git clone https://github.com/finos-labs/dtcch-2026-opsflow-llc.git
cd dtcch-2026-opsflow-llc
pnpm install

Create a .env.local file:

# Required: at least one provider
GOOGLE_GENERATIVE_AI_API_KEY=your-gemini-key

# Optional: additional LLM providers
ANTHROPIC_API_KEY=your-claude-key
OPENAI_API_KEY=your-openai-key
XAI_API_KEY=your-grok-key

# Optional: GitHub integration (enables PR generation)
GITHUB_TOKEN=your-github-token

Run

pnpm dev          # Start dev server at http://localhost:3000

Visit the dashboard — click "Demo Mode" to see CALMGuard analyze a sample architecture without any API keys.

Architecture

graph TB
    subgraph Client["Dashboard (React + React Flow)"]
        UI[Interactive UI]
        SSE[SSE EventSource]
        Store[Zustand Store]
        LS[Learning Store<br/>localStorage]
    end

    subgraph API["Next.js API Routes"]
        Parse[CALM Parser]
        Stream[SSE Stream]
        GH[GitHub API]
    end

    subgraph Phase0["Phase 0 — Deterministic"]
        Oracle["Oracle<br/>Learned Rules"]
    end

    subgraph Phase1["Phase 1 — Parallel LLM"]
        AA[Scout<br/>Architecture Analyzer]
        CM[Ranger<br/>Compliance Mapper]
        PG[Arsenal<br/>Pipeline Generator]
        CI[Cloud Infra<br/>Terraform Generator]
    end

    subgraph Phase2["Phase 2 — Sequential LLM"]
        RS[Sniper<br/>Risk Scorer]
    end

    subgraph Skills["Compliance Skills"]
        SOX[SOX.md]
        PCI[PCI-DSS.md]
        NIST[NIST-CSF.md]
        CCC[FINOS-CCC.md]
        SOC2[SOC2.md]
        PROTO[PROTOCOL-SECURITY.md]
        DEVSEC[DEVSECOPS-PIPELINE.md]
    end

    subgraph Providers["LLM Providers"]
        Gemini[Google Gemini]
        Claude[Anthropic Claude]
        GPT[OpenAI GPT]
        Grok[xAI Grok]
    end

    UI --> SSE --> Stream
    Stream --> Store --> UI
    GH --> Parse
    LS --> Oracle
    Parse --> Oracle --> AA & CM & PG & CI
    AA & CM & PG & CI --> RS
    Skills -.-> CM
    PROTO -.-> PG
    DEVSEC -.-> PG
    AA & CM & PG & CI & RS -.-> Providers
    AA & CM & PG & CI & RS --> Stream
    RS --> LS

Tech Stack

Layer	Technology	Purpose
Framework	Next.js 15 (App Router)	Full-stack React with API routes
Language	TypeScript (strict)	Type-safe codebase, zero `any`
AI	Vercel AI SDK	Structured output via `generateObject` + Zod
LLM Providers	Gemini, Claude, GPT, Grok	Multi-provider with configurable default
CALM	@finos/calm-cli v1.33	FINOS Architecture-as-Code — multi-version support (v1.0, v1.1, v1.2)
Visualization	React Flow + Recharts	Interactive architecture graphs + compliance charts
State	Zustand	Single store, SSE-driven updates
UI	shadcn/ui + Tailwind CSS	Dark theme, accessible components
Validation	Zod	Runtime schema validation for all data boundaries
Streaming	Server-Sent Events	Real-time agent event delivery

Agent System

CALMGuard runs a coordinated squad of 6 AI agents with tactical callsigns. LLM agents are defined as YAML configurations (calmguard/v1 API) in agents/:

Callsign	Agent	Phase	Role	Model
HQ	Orchestrator	All	Coordinate multi-agent lifecycle — Phase 0 pre-checks, parallel Phase 1, sequential Phase 2, event streaming, result aggregation, graceful degradation	Controller (no LLM)
Oracle	Learning Engine	0	Fire deterministic rules from previously learned patterns — zero-latency, no LLM calls. Instant compliance findings before any AI agent starts	Deterministic (no LLM)
Scout	Architecture Analyzer	1	Extract structural insights — components, data flows, trust boundaries, security zones, protocol usage, deployment topology	Gemini 2.5-flash
Ranger	Compliance Mapper	1	Map CALM controls to SOX, PCI-DSS, FINOS CCC, NIST-CSF, SOC2. Assess compliance status, identify gaps, generate per-framework scores with auditor evidence	Gemini 2.5-flash
Arsenal	Pipeline Generator	1	Generate DevSecOps CI pipelines with SAST (Semgrep), secret detection (Gitleaks), SCA (Trivy), SBOM (Syft) — stages derived from CALM signals. Security-focused Terraform IaC from protocol requirements	Gemini 2.5-flash
Sniper	Risk Scorer	2	Aggregate all Phase 1 results into weighted risk assessment — overall score (0-100), per-framework scores, node-level risk heat map, executive summary	Gemini 2.5-flash

Three-phase orchestration:

Phase 0 (Oracle): Deterministic pre-checks — fires learned rules instantly, no LLM latency
Phase 1 (Parallel): Scout + Ranger + Arsenal run concurrently via Promise.allSettled
Phase 2 (Sequential): Sniper aggregates Phase 0 + Phase 1 results into final risk assessment

All agents emit typed SSE events (started, thinking, finding, completed) streamed to the dashboard in real-time.

Compliance Skills

CALMGuard's compliance intelligence is powered by skill files — markdown documents in skills/ that inject deep regulatory knowledge into agent prompts. Each skill file contains framework-specific control mappings, CALM field correlations, and Closed Control ID Reference tables with CITE EXACTLY AS SHOWN instructions to prevent LLM hallucination of control IDs.

Skill File	Framework	Content	Agent
`SOX.md`	Sarbanes-Oxley	SOX 404 ITGC controls, COSO framework mappings	Ranger
`PCI-DSS.md`	PCI DSS 4.0	19 CALM-relevant requirements (Req 2.2.1–12.6.2), closed ID reference	Ranger
`NIST-CSF.md`	NIST CSF 2.0	21 subcategory IDs across all 6 functions (GV, ID, PR, DE, RS, RC)	Ranger
`FINOS-CCC.md`	FINOS Common Cloud Controls	Cloud-native security controls	Ranger
`SOC2.md`	SOC2 TSC	21 AICPA Trust Service Criteria (CC6.x, CC7.x, CC8.x, CC9.x)	Ranger
`PROTOCOL-SECURITY.md`	Cross-framework	Protocol upgrade mappings (HTTP→HTTPS, FTP→SFTP, etc.) with PCI-DSS + NIST + SOC2 grounding	Arsenal
`DEVSECOPS-PIPELINE.md`	DevSecOps CI	Compliance-first pipeline generation — stage selection rules, tool configs, CALM signal mapping	Arsenal

Skills are loaded at runtime via loadSkillsForAgent() and injected as knowledge blocks in agent prompts. This gives agents grounded, auditable regulatory knowledge rather than relying on parametric LLM memory.

Learning Intelligence

CALMGuard includes a self-learning compliance engine that gets smarter with every analysis:

Pattern Extraction — After each analysis, the engine fingerprints recurring compliance patterns from structural triggers (protocols, node types, relationships, missing controls)
Confidence Tracking — Each pattern tracks observation count and confidence score across runs
Auto-Promotion — When a pattern is observed 3+ times with 75%+ confidence, it's automatically promoted to a deterministic rule
Phase 0 Pre-Checks — On the next analysis, Oracle fires these deterministic rules instantly (no LLM) before any AI agent starts
Persistence — All patterns, rules, and run history persist in localStorage across sessions

The Learning Intelligence dashboard panel shows:

Intelligence Score (0-100) — weighted from pattern coverage, confidence, rule maturity, and run history
Pattern Library — all discovered compliance patterns sorted by confidence
Learning Curve — Recharts visualization of intelligence growth over time

"Run it once, it learns. Run it three times, it auto-generates deterministic compliance rules. By run 4, Oracle fires instant findings before the LLM even starts."

Pipeline Generation Capabilities

Arsenal generates DevSecOps CI pipelines derived directly from CALM architectural signals. Every security stage maps to a decision visible in your architecture definition — making the pipeline auditable and compliance-justified.

Generated Artifacts

Artifact	What It Produces	Derived From
GitHub Actions Workflow	Complete CI YAML (40-60 lines) with multi-stage DevSecOps gates	CALM node types, protocols, relationships
Security Scanning Configs	Tool-specific configs (10-20 lines each) for 2-3 tools	CALM node types + compliance controls
Infrastructure as Code	Security-focused Terraform (20-40 lines) with compliance controls	CALM protocol requirements + relationships
Recommendations	3-4 actionable items mapping CALM signals to compliance frameworks	Full CALM analysis

DevSecOps CI Stages

Generated pipelines include these stages, selected based on what CALM tells Arsenal about the architecture:

code-quality ──▶ ┌─ sast ─────────────┐
                 ├─ secret-detection ──┤ ──▶ build (compliance gate)
                 ├─ sca ──────────────┤
                 └─ sbom ─────────────┘

Stage	Tool	Purpose	CALM Signal That Triggers It
SAST	Semgrep	Static code analysis — SQL injection, XSS, insecure crypto	Always (adapts rules to node types: DB→SQLi, webclient→XSS)
Secret Detection	Gitleaks	Detect leaked credentials, API keys, tokens	Always (universal compliance requirement)
SCA	Trivy / npm-audit	Dependency vulnerability scanning	`service` or `ecosystem` nodes present
SBOM	Syft	Software Bill of Materials for audit trail	Compliance controls present in CALM
Code Quality	ESLint + TypeCheck	Lint and type safety gate	Always
Build	Compile + artifacts	Final gate — only passes if all security stages pass	Always

Security Scanning Tools

Tool	Category	What It Detects	When Selected
Semgrep	SAST	Code patterns (SQLi, XSS, CSRF, insecure crypto, hardcoded secrets)	Always — rules tuned to CALM architecture
CodeQL	SAST	Language-specific vulnerability detection	Alternative for complex architectures
Trivy	SCA	Container and dependency CVEs	When service/database nodes present
npm-audit	SCA	Node.js dependency vulnerabilities	When webclient nodes present
Gitleaks	Secrets	Leaked credentials, API keys, private keys	Always
Syft	SBOM	Software Bill of Materials (CycloneDX format)	When compliance controls present

Infrastructure as Code

Terraform configs map CALM protocol requirements to cloud security controls:

CALM Signal	Generated Terraform Rule
HTTPS relationships	Allow port 443, deny port 80
Database connections	Restrict to service CIDR only
mTLS relationships	Reference certificate resources
Network segmentation	VPC/subnet isolation

CALM Signal → Pipeline Mapping

Arsenal reads the CALM architecture and makes deterministic decisions about what to include:

CALM Signal	Pipeline Decision
Has `database` nodes	SAST with SQL injection rules
Has `webclient` nodes	SAST with XSS/CSRF rules, npm-audit for SCA
Has `service` nodes	Trivy dependency scanning
Has `ecosystem` nodes	SCA for supply chain risk
Uses HTTP (not HTTPS)	WARNING comment + upgrade recommendation
Has compliance controls	SBOM generation for audit trail
Any architecture	Secret detection + SAST + build gate

Arsenal is guided by the DEVSECOPS-PIPELINE.md skill file — a compliance-first CI generation guide injected into its prompt at runtime.

GitOps Integration

CALMGuard connects directly to GitHub repositories for a complete compliance-as-code workflow:

Fetch CALM from GitHub — enter owner/repo and file path, CALMGuard fetches and parses the architecture
DevSecOps CI Pipeline PRs — generate and push GitHub Actions workflows with security scanning
Compliance Remediation PRs — generate CALM architecture changes that close compliance gaps
SHA Tracking — all PRs track the source file SHA for auditability

Requires a GITHUB_TOKEN in .env.local for PR generation.

Remediation in Action

CALMGuard doesn't just report compliance gaps — it fixes them. Here's a real CALM architecture before and after automated remediation:

	Repository	Description
Before	`payment-gateway.calm.json`	Original architecture with compliance gaps — weak protocols, missing controls
After	`payment-gateway.calm.json`	CALMGuard-remediated — near 100% compliant across all 5 frameworks

The remediation PR upgrades protocols (JDBC→TLS, HTTP→HTTPS), adds missing security controls (PCI-DSS, NIST-CSF, SOX, SOC2), and preserves all original architecture elements. LLM agents identify the gaps; deterministic code applies the fixes.

Demo Architectures

Two production-realistic CALM architectures are included in examples/:

Architecture	Description
Payment Gateway	Multi-service payment processing with encryption, tokenization, PCI controls
Trading Platform	Real-time trading system with market data feeds, order management, risk engine

Multi-Version CALM Support

CALMGuard supports all three stable releases of the FINOS CALM specification — v1.0, v1.1, and v1.2. The parser automatically detects the version, normalizes fields to a common internal representation, and passes clean data to agents. No user action required — just upload any CALM file.

Version Detection

Version is detected automatically by schema inference — examining which fields are present:

Version	Detection Signal	Key Characteristics
CALM v1.0	`calmSchemaVersion` field present	Legacy node types (`apigateway`, `microservice`), legacy relationship types (`uses`)
CALM v1.1	`description` on flow transitions, standard `node-type` enum	Standard node types (`service`, `database`, `webclient`, etc.)
CALM v1.2	Optional `decorators`, `timelines`, `adrs` fields	All v1.1 features plus ADRs and timeline tracking

If version is ambiguous, the parser defaults to the latest (v1.2) and parses leniently.

Legacy Type Mapping

CALM v1.0 uses node and relationship types that were renamed in v1.1. The parser maps these automatically:

v1.0 Legacy Type	Maps To	Category
`apigateway`	`service`	Node type
`microservice`	`service`	Node type
`uses`	`connects`	Relationship type

Unknown node types (e.g., lambda) are mapped to service — maximizing compatibility over strictness.

Backward Compatibility

Missing fields are filled with sensible defaults (empty string, empty array) — the file parses successfully, agents work with what's available
Lenient validation accepts unknown field values and legacy aliases
Version badge shown on the dashboard next to parsed node/relationship counts (e.g., "CALM v1.1 — 8 nodes, 6 relationships")
No breaking changes — existing v1.1 demo files (payment-gateway, trading-platform) continue working without regression

CALMGuard's parser extends the existing pattern of handling CALM CLI output with lenient aliases. Multi-version support is a parser-layer change — transparent to the AI agent system.

Documentation

Full documentation is available in docs/. Run locally with pnpm docs:dev, or browse directly on GitHub:

Getting Started

Guide	Description
Introduction	What CALMGuard is, the problem it solves, and key capabilities
Getting Started	Setup, environment variables, running your first analysis
Uploading Architectures	CALM file format, validation, using demo architectures
Reading Reports	Dashboard walkthrough — interpreting compliance scores, heat maps, findings

Architecture & Internals

Guide	Description
System Overview	Architecture diagram, data flow, SSE streaming, Zustand store
Agent System	Agent definitions, orchestration phases, YAML configs, skill injection
API Reference	HTTP endpoints — `POST /api/analyze`, `POST /api/calm/parse`, `GET /api/pipeline`
Compliance Frameworks	NIST CSF, PCI DSS, SOX, FINOS CCC — how they map to CALM controls

Project

Guide	Description
Product Roadmap	12-phase path from hackathon prototype to enterprise compliance platform
Contributing	Development setup, branch naming, commit conventions, CI requirements
Security	Threat model, input validation, LLM output safety, responsible AI
SECURITY.md	Full security policy with AI-specific threat analysis
CHANGELOG.md	Release history and version details

Contributing

We welcome contributions! See CONTRIBUTING.md for:

Development setup and workflow
Branch naming and commit conventions (Conventional Commits)
CI pipeline requirements
Code standards (TypeScript strict, Zod schemas, dark theme)

All commits must include a DCO sign-off (git commit -s).

Roadmap — Path to Enterprise

CALMGuard is designed as a platform, not a point solution. The hackathon demonstrates the core compliance loop; the full product roadmap charts 12 phases from prototype to enterprise-grade continuous compliance platform.

Near-term (Phases 2-5):

Phase	Capability	Impact
Intelligent Pipelines	DAST, mTLS verification, policy-as-code gates derived from CALM signals	Pipelines that are architecture-aware, not templated
Runtime Drift Detection	CALM vs live infrastructure (AWS/Azure/GCP/K8s) comparison	Catch compliance drift in hours, not quarterly audits
Pre-Deployment Validation	CI gate + PR bot that blocks non-compliant changes	Shift-left compliance — fail fast, fix before production
CALMGuard as a Service	MCP server + REST API + CLI + GitHub App	Any tool, agent, or pipeline can invoke compliance checks

Mid-term (Phases 6-9):

Phase	Capability	Impact
Flow-Based Risk Modeling	Risk scoring along CALM data flows, cascading risk, blast radius estimation	Risk follows data paths, not just node attributes
Secure IaC Generation	Production-ready Terraform, K8s manifests, Helm charts from CALM	Infrastructure that is compliant by construction
Persistent Intelligence	PostgreSQL backend, cross-team learning, versioned skills	Enterprise-grade learning that survives restarts
Graph Intelligence	GNN-based architecture analysis, vectorized reasoning bank, architecture embeddings	Structural compliance reasoning beyond pattern matching

Long-term (Phases 10-12):

Phase	Capability	Impact
Adaptive Pen Testing	CALM-guided penetration testing that evolves with the architecture	Test actual attack paths, not random endpoints
Enterprise Deployment	Air-gapped, multi-tenant, SSO/RBAC, SOC2 Type II evidence	Production-ready for regulated financial institutions
Global Learning Network	Federated compliance intelligence, industry benchmarks, community skills	Cross-industry compliance knowledge that improves for everyone

Team

OpsFlow LLC — Built for DTCC/FINOS Innovate.DTCC AI Hackathon 2026

Name	Role	Background
Gourav J. Shah	Lead Engineer	DevOps domain expert with 19+ years hands-on expertise in cloud infrastructure, DevSecOps, container orchestration, and platform engineering. Creator of Agentic Ops Framework and KubeAgentiX.
Anoop Mehendale	Engineer	Serial entrepreneur with a track record of building and scaling enterprise technology companies.

Hackathon Context

This project was built for the Innovate.DTCC AI Hackathon (Feb 23–27, 2026), organized by DTCC and powered by FINOS. The challenge: leverage AI to improve DevSecOps workflows in financial services using the FINOS CALM (Common Architecture Language Model) standard.

CALMGuard demonstrates how Architecture-as-Code can be the foundation for automated, continuous compliance — turning static architecture documentation into living, actionable security intelligence.

License

Distributed under the Apache License, Version 2.0.

SPDX-License-Identifier: Apache-2.0

Acknowledgements

FINOS — Financial Open Source Foundation
CALM — Common Architecture Language Model
DTCC — Depository Trust & Clearing Corporation
Vercel AI SDK — Structured AI output framework
shadcn/ui — Beautiful accessible components
React Flow — Interactive graph visualization

Name		Name	Last commit message	Last commit date
Latest commit History 187 Commits
.github		.github
.husky		.husky
.planning		.planning
agents		agents
docs		docs
examples		examples
out		out
public		public
scripts		scripts
skills		skills
src		src
.gitignore		.gitignore
.npmrc		.npmrc
CALMGuard_Presentation_v4.0.pdf		CALMGuard_Presentation_v4.0.pdf
CHANGELOG.md		CHANGELOG.md
CLAUDE.md		CLAUDE.md
CONTRIBUTING.md		CONTRIBUTING.md
LICENSE		LICENSE
LICENSE.spdx		LICENSE.spdx
NOTICE		NOTICE
README.md		README.md
SECURITY.md		SECURITY.md
architecture-tab-after-fix.png		architecture-tab-after-fix.png
components.json		components.json
eslint.config.mjs		eslint.config.mjs
hackathon_helpful_links.md		hackathon_helpful_links.md
next-env.d.ts		next-env.d.ts
next.config.ts		next.config.ts
overview-after-fix.png		overview-after-fix.png
package.json		package.json
pnpm-lock.yaml		pnpm-lock.yaml
postcss.config.mjs		postcss.config.mjs
submission-instructions.md		submission-instructions.md
tailwind.config.ts		tailwind.config.ts
tsconfig.json		tsconfig.json
vitest.config.mts		vitest.config.mts

Folders and files

Latest commit

History

Repository files navigation

CALMGuard

Key Features

How It Works

Demo and Presentation

Watch the demo on YouTube

Quick Start

Prerequisites

Setup

Run

Architecture

Tech Stack

Agent System

Compliance Skills

Learning Intelligence

Pipeline Generation Capabilities

Generated Artifacts

DevSecOps CI Stages

Security Scanning Tools

Infrastructure as Code

CALM Signal → Pipeline Mapping

GitOps Integration

Remediation in Action

Demo Architectures

Multi-Version CALM Support

Version Detection

Legacy Type Mapping

Backward Compatibility

Documentation

Getting Started

Architecture & Internals

Project

Contributing

Roadmap — Path to Enterprise

Team

Hackathon Context

License

Acknowledgements

About

Resources

License

Code of conduct

Contributing

Security policy

Uh oh!

Stars

Watchers

Forks

Releases 2

Packages 0

Uh oh!

Contributors

Uh oh!

Languages

Packages
